为了适应公司代码全程使用jquery构造 如需其他js或者vue 可根据此代码去改（因为好多地方会用到这个东西所以我封装成了一个js文件）
研究了第二期 实现条形码的识别和上传图片识别 通过type切换 识别二维码还是条形码
欢迎大家多多观看 多多支持?下
点这进入看
?
https://dragonir.github.io/h5-scan-qrcode/#/
这个是效果 可以提前看一下~
我做的比这个效果多一个拿取本地图库的二维码扫码
scancode ---- html文件 如何引入js
scancode.js---- 封装的js文件
jsQR.js ---- 是这个插件所用的一个js可以在vue文件里面直接拿出来 可以去官网看看（不想动手的 麻烦踢踢后台的我 给你们私发！）
jquery.js ----这就不用说了吧
如果想要整个流程 后台踢我私信邮箱或者联系方式 (谢谢理解！)
scancode.html
<!doctype html><html lang="en"><head> <meta charset="UTF-8"> <meta name="viewport" content="width=device-width, user-scalable=no, initial-scale=1.0, maximum-scale=1.0, minimum-scale=1.0"> <meta http-equiv="X-UA-Compatible" content="ie=edge"> <title>Document</title> <script src="jquery-3.1.1.min.js"></script> <script type="text/javascript" src="scancode.js?v=1"></script> <script type="text/javascript" src="jsQR.js"></script></head><body><div class=""> <button id="search_scans">点击扫码</button> <input type="text" id="assetTableSearch"> //扫码内容复现到此input上</div></body><script> $(function (){ scancode({btn:$('#search_scans'),input:$('#assetTableSearch')}) })</script></html>scancode.js
