有好多私信小伙伴，问我的那篇帖子：
vue纯前端导出excel，包括列表批量导出图片、文件超链接
上篇文章只是将公司的需求代码实现粘贴了进来，对于没有使用过exceljs插件的人来说，确实是有点晦涩的，本文就按自己的理解，一步一步将exceljs插件的使用讲解一下，有不明确或理解错误的地方欢迎指出，促进我进步。
最终实现样式展示：
目录
一、exceljs的安装、引用
二、创建excel工作簿
三、创建excel工作表（sheet栏）
四、为excel工作表定义每列的数据
五、excel设置样式（合并单元格等）
六、excel的行级操作
七、遍历所有行
八、遍历所有单元格
九、向excel中插入图片
十、插入超链接
十一、主图完整代码
一、exceljs的安装、引用
首先执行npm i exceljs，将依赖安装到你的项目中
npm i exceljs在vue页面中，创建一个方法，将exceljs引入
exportExcel() {const Exceljs = require('exceljs'); // 引入exceljs},二、创建excel工作簿
引入成功后，先来创建一个excel工作簿
exportExcel() {const Exceljs = require('exceljs'); // 引入exceljsconst workbook = new Exceljs.Workbook();// 创建工作簿},此时，我们增加以下内容，就会下载出一个excel文件啦。
我用了saveAs 插件下载，安装方式随便搜一下，这里就不赘述了。
exportExcel() {const Exceljs = require('exceljs'); // 引入exceljsconst workbook = new Exceljs.Workbook(); // 创建工作簿// 下载工作簿workbook.xlsx.writeBuffer().then((buffer) => {saveAs(new Blob([buffer], { type: 'application/octet-stream' }), '测试导出.xlsx');});},如果下载成功，说明组件引入都没有问题，进行下一步操作~
三、创建excel工作表（sheet栏）
excel是可以有多个sheet栏的，创建好工作簿后，下一步一定是创建一个工作表，也就是sheet，调用 workbook.addWorksheet(‘sheet栏的名字’) ，必须用变量接收一下，因为后续要对它进行操作！
exportExcel() {const Exceljs = require('exceljs'); // 引入exceljsconst workbook = new Exceljs.Workbook(); // 创建工作簿const workSheet = workbook.addWorksheet('总报价');// 创建工作表（sheet1）},四、为excel工作表定义每列的数据
exceljs支持快速定义表头，每列的数据字段，传入表头配置数组，对应的列，就会自动赋值，与 el-table 的理念差不多，前端理解后，使用非常方便。
workSheet.columns = this.exportTableProp; // 工作表添加表头exportTableProp的格式为：
header是表头列名，key是每列的数据源，width是列宽
[ { header: '姓名', key: 'name', width: 14 }, { header: '年龄', key: 'age', width: 14 }, { header: '性别', key: 'sex', width: 14 }, { header: '生日', key: 'birth', width: 14 }]定义表头后，插入数据：
workSheet.addRows(this.exportDataList); // 往工作表插入数据将代码连起来，已经可以执行啦，导出一个完整的excel
exportExcel() {const Exceljs = require('exceljs'); // 引入exceljsconst workbook = new Exceljs.Workbook(); // 创建工作簿const workSheet = workbook.addWorksheet('sheet1');// 创建工作表（sheet1）workSheet.columns = this.exportTableProp; // 工作表添加表头workSheet.addRows(this.exportDataList);// 往工作表插入数据// 下载工作簿workbook.xlsx.writeBuffer().then((buffer) => {saveAs(new Blob([buffer], { type: 'application/octet-stream' }), '测试导出.xlsx');});},五、excel设置样式（合并单元格等）
exceljs提供了一系列方法，正确调用即可画出任何样式的excel
合并单元格：
workSheet.mergeCells('A1:M1'); //将A1到M1的单元格合并获取单元格：（设置样式的前提）
const cell = workSheet.getCell('A1'); // 获取A1单元格设置A1单元格显示的内容：
cell.value = '我是A1各自的数据';设置A1单元格的样式：
font设置文字样式，alignment设置格子内文本如何显示，fill 设置单元格背景色
cell.font = { size: 16, bold: true, name: '仿宋' }; // 设置字体大小为16，加粗，仿宋cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'A9D08E' } // 设置背景色};六、excel的行级操作
获取第一行：
workSheet.getRow(1)调整第一行的行高
workSheet.getRow(1).height = 70;手动添加一行：
workSheet.addRow();workSheet.addRow(2);workSheet.addRow(['姓名','年龄','性别']);不传参：在最下方加一行
传数字：在指定列加一行
传数组：加一行，且设置行内数据
七、遍历所有行
调用workSheet.eachRow 可以遍历所有行，比如快捷设置全部行高
workSheet.eachRow((row, rowIndex) => {// 循环每一行 console.log(row) row.height = 17;});八、遍历所有单元格
嵌套操作，可以遍历到全部单元格，代码演示：
workSheet.eachRow((row, rowIndex) => {// 循环每个单元格row.eachCell((cell, colIndex) => {cell.font = { size: 11, bold: true };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};});});当然，也可以加判断
workSheet.eachRow((row, rowIndex) => {if (rowIndex === 14) {row.eachCell((cell, colIndex) => {cell.font = { size: 11, bold: true };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};});}if (rowIndex > 14 && rowIndex <= 25) {row.height = 17;row.eachCell((cell, colIndex) => { cell.font = { size: 11 }; cell.alignment = { vertical: 'middle', // 垂直居中 horizontal: 'center', // 水平居中 wrapText: true // 自动换行 };});}});来个实用案例： 为所有单元格设置边框：
// 定义边框样式const borderStyle = {top: { style: 'thin' },left: { style: 'thin' },bottom: { style: 'thin' },right: { style: 'thin' }};// 遍历工作表中的所有单元格并添加边框workSheet.eachRow((row, rowIndex) => {row.eachCell((cell, colIndex) => {cell.border = borderStyle;});});九、向excel中插入图片
如果是base64编码图片，直接插入就可以，如果不是，需要转为base64
// 将logo放入第一行 const base64 = await this.imageToBase64(); // 这里是转base64方法，不放了// 把base64编码的图片插入excel工作簿里面const imageId = workbook.addImage({base64: base64,extension: 'png'});// 当前工作表（当前excel页）加入图片，tl.col：excel第几列，tl.row：excel第几行，ext里面表示图片宽高workSheet.addImage(imageId, {tl: { col: 0.1, row: 0.1 },// br: { col: columns.length + ai - 11.1, row: ri + 2 }ext: { width: 100, height: 85 }});十、插入超链接
超链接一定是单元格级别的，先获取到单元格，然后设置value即可
cell.value = {text: '要显示的文字',hyperlink: 'www.baidu.com',tooltip: 'hover的提示'};将上述操作全部用上，相信你的excel就可以任意定义啦~
十一、主图完整代码
最后，附主图的完整屎山代码，接口就不放了
async exportExcel(row) {const loading = this.$loading({lock: true,text: '导出excel中...（若长时间无响应请刷新页面）',spinner: 'el-icon-loading',background: 'rgba(0, 0, 0, 0.7)'});// 查商务报价版本let para = {CommercialQuotationVersionId: row.commercialQuotationVersionId};let res = await GetCommercialQuotationVersion(para);if (res.success) {let totalQuotationData = res.response;const Exceljs = require('exceljs');// 创建工作簿const workbook = new Exceljs.Workbook();// 创建工作表（sheet1）const workSheet = workbook.addWorksheet('总报价');// 表格的表头配置workSheet.columns = this.exportTableProp; // 工作表添加表头//======================================= 第一行 =================================// 合并A1到L1的单元格 （大标题）workSheet.mergeCells('A1:M1');const cell = workSheet.getCell('A1');cell.value = 'Mechanical CO., LTD. - Quotation - 报价单';// 设置第一行的单元格样式cell.font = { size: 16, bold: true, name: '仿宋' }; // 设置字体大小为16，加粗，仿宋cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};// 调整第一行的高度workSheet.getRow(1).height = 70;// ==================================== 第二 到 第十二行 ================= 样式差不多，一起搞for (let ri = 2; ri < 14; ri++) {// 创建第ri行workSheet.addRow(ri);// 合并单元格workSheet.mergeCells(`A${ri}:C${ri}`);workSheet.mergeCells(`D${ri}:F${ri}`);workSheet.mergeCells(`G${ri}:I${ri}`);workSheet.mergeCells(`J${ri}:M${ri}`);// A列的标题数据let headerCellA = workSheet.getCell(`A${ri}`);headerCellA.value = this.excelHeader[(ri - 2) * 2].label;headerCellA.alignment = {vertical: 'middle' // 垂直居中};if (ri <= 10) {headerCellA.font = { size: 11, name: '仿宋' };} else {headerCellA.font = { size: 11, name: '仿宋', bold: true, color: { argb: 'FF0000' } };}// D列let headerCellD = workSheet.getCell(`D${ri}`);if (ri > 10) {headerCellD.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'FFD966' } // 设置背景色};}headerCellD.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};// G列let headerCellG = workSheet.getCell(`G${ri}`);headerCellG.value = this.excelHeader[(ri - 1) * 2 - 1].label;headerCellG.alignment = {vertical: 'middle' // 垂直居中};if (ri <= 10) {headerCellG.font = { size: 11, name: '仿宋' };} else {headerCellG.font = { size: 11, name: '仿宋', bold: true, color: { argb: 'FF0000' } };}// J列let headerCellJ = workSheet.getCell(`J${ri}`);if (ri > 10 && ri !== 13) {headerCellJ.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'FFD966' } // 设置背景色};}headerCellJ.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};workSheet.getRow(ri).height = 15;// 获取第ri行的单元格// const cell = workSheet.getCell(`A${ri}`);// 设置单元格样式}// 插入表头一堆数据 row 是主表数据 totalQuotationData 是子表数据workSheet.getCell('D2').value = row.inquiryName; // 项目名称workSheet.getCell('D3').value = row.commercialQuotationNumber; // 报价单号workSheet.getCell('J3').value = row.creationTime; // 报价日期workSheet.getCell('D4').value = row.customer; // 客户名称workSheet.getCell('D11').value = ''; // 交费周期let string = '';this.PaymentMethod.forEach((item) => {if (item.key === totalQuotationData.paymentMethod) {string = item.value;}});workSheet.getCell('J11').value = string; // 付款方式workSheet.getCell('D12').value = totalQuotationData.customerRequirementVersion; // 技术要求版本号workSheet.getCell('J12').value = totalQuotationData.versionNumber; // 报价版本号workSheet.getCell('D13').value = totalQuotationData.solutionVersion; // 方案版本号// ================================ 数据部分行 =============================================================workSheet.addRow(this.exportTableProp.map((item) => {return item.header;}));// 添加数据，表头信息已经在最上面定好了（这里是从接口取回来的数据）totalQuotationData.commercialQuotationVersionWorkstationList.forEach((item, index) => {for (let key in item) {if (item[key] === null) item[key] = '';}item.index = index + 1;});let tableData = totalQuotationData.commercialQuotationVersionWorkstationList;workSheet.addRows(tableData);// 设置第14行到数据结束 行的所有单元格的样式workSheet.eachRow((row, rowIndex) => {// 循环每一行if (rowIndex === 14) {row.eachCell((cell, colIndex) => {cell.font = { size: 11, bold: true };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};});}if (rowIndex > 14 && rowIndex <= 14 + tableData.length) {row.height = 17;row.eachCell((cell, colIndex) => {cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};});}});// =======================================最下方合计部分 ============================================// ======================================= 成本小计行 ==========================================let rowNUM = 15 + tableData.length; // 从第几行开始workSheet.addRow();workSheet.mergeCells(`A${rowNUM}:C${rowNUM}`);workSheet.getCell(`A${rowNUM}`).value = '成本小计';// 下面是 成本小计行的数据workSheet.getCell(`D${rowNUM}`).value = totalQuotationData.mechanicalMaterialsAndProcessingCosts_TotalCost || '';workSheet.getCell(`E${rowNUM}`).value = totalQuotationData.mechanicalPurchaseCost_TotalCost || '';workSheet.getCell(`F${rowNUM}`).value = totalQuotationData.electricalpurchaseCost_TotalCost || '';workSheet.getCell(`G${rowNUM}`).value = totalQuotationData.industrialControlCost_TotalCost || '';workSheet.getCell(`H${rowNUM}`).value = totalQuotationData.totalHardwareCost_TotalCost || '';workSheet.getCell(`I${rowNUM}`).value = totalQuotationData.laborCost_TotalCost || '';workSheet.getCell(`J${rowNUM}`).value = totalQuotationData.travelAndAccommodationCost_TotalCost || '';workSheet.getCell(`K${rowNUM}`).value = totalQuotationData.transportationAndOtherMaterialCosts_TotalCost || '';workSheet.getCell(`L${rowNUM}`).value = totalQuotationData.totalCost || '';workSheet.getCell(`M${rowNUM}`).value = totalQuotationData.costSubtotal_Remarks || '';// 设置成本小计样式workSheet.eachRow((row, rowIndex) => {if (rowIndex === rowNUM) {row.eachCell((cell, colIndex) => {cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};// 除备注列外，其他列设置颜色if (cell._address.indexOf('M') < 0) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'F8CBAD' } // 设置背景色};}});row.height = 17;}});// =================================================== 其他合计行 ===================================================let otherSunRow = [{name: '成本合计（未税）/ 元',prop: 'totalCost',remark: 'totalCost_Remarks'},{name: '管理费 / 元：',prop: 'managementFee_TotalCost',remark: 'managementFee_Remarks'},{name: '财务费 / 元：',prop: 'financialFee_TotalCost',remark: 'financialFee_Remarks'},{name: '利润 / 元：',prop: 'profit_TotalCost',remark: 'profit_Remarks'},{name: '价格合计（未税）/ 元：',prop: 'totalPriceExcludingTax_TotalCost',remark: 'totalPriceExcludingTax_Remarks'},{name: '增值税 / 元：',prop: 'valueAddedTax_TotalCost',remark: 'valueAddedTax_Remarks'},{name: '价格合计（含税）/ 元：',prop: 'totalPriceIncludingTax_TotalCost',remark: 'totalPriceIncludingTax_Remarks'},{name: '优惠后价格（含税）/ 元：',prop: 'discountedPrice',remark: 'discountedPrice_Remarks'},{name: '针对此次报价的其他说明',prop: 'remarks',remark: 'remarks'}];// 如果没有优惠后价格就不显示let havePrice = true;if (totalQuotationData.discountedPrice === null || totalQuotationData.discountedPrice === '' || totalQuotationData.discountedPrice === undefined) {havePrice = false;otherSunRow = otherSunRow.filter((item) => {return item.prop !== 'discountedPrice';});}// 插入数据let otherNum = rowNUM + 1;for (let oi = 0; oi < otherSunRow.length; oi++) {workSheet.addRow();workSheet.mergeCells(`A${oi + otherNum}:C${oi + otherNum}`);workSheet.getCell(`A${oi + otherNum}`).value = otherSunRow[oi].name || '';if (oi === otherSunRow.length - 1) {workSheet.mergeCells(`D${oi + otherNum}:M${oi + otherNum}`);} else {workSheet.mergeCells(`D${oi + otherNum}:L${oi + otherNum}`);}workSheet.getCell(`D${oi + otherNum}`).value = totalQuotationData[otherSunRow[oi].prop] || '';workSheet.getCell(`M${oi + otherNum}`).value = totalQuotationData[otherSunRow[oi].remark] || '';}// 设置其他合计样式workSheet.eachRow((row, rowIndex) => {if (rowIndex > rowNUM && rowIndex < rowNUM + otherSunRow.length + 1) {if (rowIndex === rowNUM + 6) {row.height = 17;// 增值税row.eachCell((cell, colIndex) => {cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};// 除备注列外，其他列设置颜色if (cell._address.indexOf('M') < 0) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: '9BC2E6' } // 设置背景色};}});} else if (rowIndex === rowNUM + 7 || (havePrice ? rowIndex === rowNUM + 8 : false)) {row.height = 17;// 价税合计 、优惠后价格row.eachCell((cell, colIndex) => {cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};if (cell._address.indexOf('M') < 0) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'FFD966' } // 设置背景色};}});} else if (havePrice ? rowIndex === rowNUM + 9 : rowIndex === rowNUM + 8) {row.height = 17;// 最后的其他说明row.eachCell((cell, colIndex) => {cell.font = { size: 11, bold: true };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'A9D08E' } // 设置背景色};});} else {row.height = 17;row.eachCell((cell, colIndex) => {cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};if (cell._address.indexOf('M') < 0) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'F8CBAD' } // 设置背景色};}});}}});// 将logo放入第一行 放到最后就行啦// 获取图片的 Blob 数据const base64 = await this.imageToBase64();// 把base64编码的图片插入excel工作簿里面const imageId = workbook.addImage({base64: base64,extension: 'png'});// 当前工作表（当前excel页）加入图片，tl.col：excel第几列，tl.row：excel第几行，ext里面表示图片宽高workSheet.addImage(imageId, {tl: { col: 0.1, row: 0.1 },// br: { col: columns.length + ai - 11.1, row: ri + 2 }ext: { width: 100, height: 85 }});// 调整所有列的宽度workSheet.columns.forEach((column) => {column.width = 17; // 将宽度设为20个字符});// 定义边框样式const borderStyle = {top: { style: 'thin' },left: { style: 'thin' },bottom: { style: 'thin' },right: { style: 'thin' }};// 遍历工作表中的所有单元格并添加边框workSheet.eachRow((row, rowIndex) => {row.eachCell((cell, colIndex) => {cell.border = borderStyle;});});// =================================== 工位 Sheet =======================================var that = this;async function getData() {let details = totalQuotationData.commercialQuotationVersionWorkstationList; // 这是所有工位for (let i = 0; i < details.length; i++) {let spara = {CommercialQuotationVersionWorkstationId: details[i].commercialQuotationVersionWorkstationId};let sres = await GetCommercialQuotationVersionWorkstation(spara);console.log('工位', sres);let tableData = sres.response;// 创建工位的工作表let sworkSheet = workbook.addWorksheet(details[i].inquiryStationCode);//======================================= 第一行 =================================// 合并A1到L1的单元格 （大标题）sworkSheet.mergeCells('A1:L1');const cell = sworkSheet.getCell('A1');cell.value = 'ChangChun HeXin Mechanical Manufacturing CO., LTD. - Quotation 长春合心机械制造有限公司 - 报价单';// 设置第一行的单元格样式cell.font = { size: 16, bold: true, name: '仿宋' }; // 设置字体大小为16，加粗，仿宋cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};// 调整第一行的高度sworkSheet.getRow(1).height = 70;// ==================================== 第二 到 第十二行 ================= 样式差不多，一起搞for (let ri = 2; ri < 14; ri++) {// 创建第ri行sworkSheet.addRow(ri);// 合并单元格sworkSheet.mergeCells(`A${ri}:C${ri}`);sworkSheet.mergeCells(`D${ri}:F${ri}`);sworkSheet.mergeCells(`G${ri}:I${ri}`);sworkSheet.mergeCells(`J${ri}:L${ri}`);// A列的标题数据let headerCellA = sworkSheet.getCell(`A${ri}`);headerCellA.value = that.excelHeader[(ri - 2) * 2].label;headerCellA.alignment = {vertical: 'middle' // 垂直居中};if (ri <= 10) {headerCellA.font = { size: 11, name: '仿宋' };} else {headerCellA.font = { size: 11, name: '仿宋', bold: true, color: { argb: 'FF0000' } };}// D列let headerCellD = sworkSheet.getCell(`D${ri}`);if (ri > 10) {headerCellD.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'FFD966' } // 设置背景色};}headerCellD.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};// G列let headerCellG = sworkSheet.getCell(`G${ri}`);headerCellG.value = that.excelHeader[(ri - 1) * 2 - 1].label;headerCellG.alignment = {vertical: 'middle' // 垂直居中};if (ri <= 10) {headerCellG.font = { size: 11, name: '仿宋' };} else {headerCellG.font = { size: 11, name: '仿宋', bold: true, color: { argb: 'FF0000' } };}// J列let headerCellJ = sworkSheet.getCell(`J${ri}`);if (ri > 10 && ri !== 13) {headerCellJ.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'FFD966' } // 设置背景色};}headerCellJ.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};sworkSheet.getRow(ri).height = 15;// 获取第ri行的单元格// const cell = sworkSheet.getCell(`A${ri}`);// 设置单元格样式}// 插入表头一堆数据 row 是主表数据 totalQuotationData 是子表数据sworkSheet.getCell('D2').value = row.inquiryName; // 项目名称sworkSheet.getCell('D3').value = row.commercialQuotationNumber; // 报价单号sworkSheet.getCell('J3').value = row.creationTime; // 报价日期sworkSheet.getCell('D4').value = row.customer; // 客户名称sworkSheet.getCell('D11').value = ''; // 交费周期let string = '';that.PaymentMethod.forEach((item) => {if (item.key === totalQuotationData.paymentMethod) {string = item.value;}});sworkSheet.getCell('J11').value = string; // 付款方式sworkSheet.getCell('D12').value = totalQuotationData.customerRequirementVersion; // 技术要求版本号sworkSheet.getCell('J12').value = totalQuotationData.versionNumber; // 报价版本号sworkSheet.getCell('D13').value = totalQuotationData.solutionVersion; // 方案版本号// ==================================== 工位的数据部分 =================================================// 标题行 ['No.','Item 项目','小时数','费率','Price 价格','备注：']sworkSheet.addRow();sworkSheet.getCell('A14').value = 'No.';sworkSheet.mergeCells(`B14:C14`);sworkSheet.getCell('B14').value = 'Item 项目';sworkSheet.getCell('D14').value = '小时数';sworkSheet.getCell('E14').value = '费率';sworkSheet.getCell('F14').value = 'Price 价格';sworkSheet.getCell('G14').value = '备注：';sworkSheet.mergeCells(`G14:L14`);// 机械材料成本sworkSheet.addRow();sworkSheet.getCell('A15').value = 1; // 序号sworkSheet.mergeCells(`B15:C15`);sworkSheet.getCell('B15').value = '机械材料成本';sworkSheet.getCell('D15').value = '/'; // 小时数sworkSheet.getCell('E15').value = '/'; // 费率sworkSheet.getCell('F15').value = ''; // 价格sworkSheet.getCell('G15').value = ''; // 备注sworkSheet.mergeCells(`G15:L15`);// 机械加工成本sworkSheet.addRow();sworkSheet.getCell('A16').value = 2;sworkSheet.mergeCells(`B16:C16`);sworkSheet.getCell('B16').value = '机械加工成本';sworkSheet.getCell('D16').value = '/'; // 小时数sworkSheet.getCell('E16').value = '/'; // 费率sworkSheet.getCell('F16').value = tableData.mechanicalMaterialsAndProcessingCosts_AfterMarkup || ''; // 价格sworkSheet.getCell('G16').value = tableData.mechanicalMaterialsAndProcessingCosts_Remarks || ''; // 备注sworkSheet.mergeCells(`G16:L16`);// 机械采购成本sworkSheet.addRow();sworkSheet.getCell('A17').value = 3;sworkSheet.mergeCells(`B17:C17`);sworkSheet.getCell('B17').value = '机械采购成本';sworkSheet.getCell('D17').value = '/'; // 小时数sworkSheet.getCell('E17').value = '/'; // 费率sworkSheet.getCell('F17').value = tableData.mechanicalPurchaseCost_AfterMarkup || ''; // 价格sworkSheet.getCell('G17').value = tableData.mechanicalPurchaseCost_Remarks || ''; // 备注sworkSheet.mergeCells(`G17:L17`);// 型材及配件sworkSheet.addRow();sworkSheet.getCell('A18').value = 4;sworkSheet.mergeCells(`B18:C18`);sworkSheet.getCell('B18').value = '型材及配件';sworkSheet.getCell('D18').value = '/'; // 小时数sworkSheet.getCell('E18').value = '/'; // 费率sworkSheet.getCell('F18').value = ''; // 价格sworkSheet.getCell('G18').value = ''; // 备注sworkSheet.mergeCells(`G18:L18`);// 电气采购成本sworkSheet.addRow();sworkSheet.getCell('A19').value = 5;sworkSheet.mergeCells(`B19:C19`);sworkSheet.getCell('B19').value = '电气采购成本';sworkSheet.getCell('D19').value = '/'; // 小时数sworkSheet.getCell('E19').value = '/'; // 费率sworkSheet.getCell('F19').value = tableData.electricalpurchaseCost_AfterMarkup || ''; // 价格sworkSheet.getCell('G19').value = tableData.electricalpurchaseCost_Remarks || ''; // 备注sworkSheet.mergeCells(`G19:L19`);// 机械设计费sworkSheet.addRow();sworkSheet.getCell('A20').value = 6;sworkSheet.mergeCells(`B20:C20`);sworkSheet.getCell('B20').value = '机械设计费';sworkSheet.getCell('D20').value = tableData.mechanicalDesignFee_Hours || ''; // 小时数sworkSheet.getCell('E20').value = tableData.mechanicalDesignFee_PerHourRate || ''; // 费率sworkSheet.getCell('F20').value = tableData.mechanicalDesignFee_TotalCost || ''; // 价格sworkSheet.getCell('G20').value = tableData.mechanicalDesignFee_Remarks || ''; // 备注sworkSheet.mergeCells(`G20:L20`);// 电气设计费sworkSheet.addRow();sworkSheet.getCell('A21').value = 7;sworkSheet.mergeCells(`B21:C21`);sworkSheet.getCell('B21').value = '电气设计费';sworkSheet.getCell('D21').value = tableData.electricalDesignFee_Hours || ''; // 小时数sworkSheet.getCell('E21').value = tableData.electricalDesignFee_PerHourRate || ''; // 费率sworkSheet.getCell('F21').value = tableData.electricalDesignFee_TotalCost || ''; // 价格sworkSheet.getCell('G21').value = tableData.electricalDesignFee_Remarks || ''; // 备注sworkSheet.mergeCells(`G21:L21`);// 软件编程及开发sworkSheet.addRow();sworkSheet.getCell('A22').value = 8;sworkSheet.mergeCells(`B22:C22`);sworkSheet.getCell('B22').value = '软件编程及开发';sworkSheet.getCell('D22').value = tableData.softwareProgramming_Hours || ''; // 小时数sworkSheet.getCell('E22').value = tableData.softwareProgramming_PerHourRate || ''; // 费率sworkSheet.getCell('F22').value = tableData.softwareProgramming_TotalCost || ''; // 价格sworkSheet.getCell('G22').value = tableData.softwareProgramming_Remarks || ''; // 备注sworkSheet.mergeCells(`G22:L22`);// 机器人调试sworkSheet.addRow();sworkSheet.getCell('A23').value = 9;sworkSheet.mergeCells(`B23:C23`);sworkSheet.getCell('B23').value = '机器人调试';sworkSheet.getCell('D23').value = tableData.robotDebugging_Hours || ''; // 小时数sworkSheet.getCell('E23').value = tableData.robotDebugging_PerHourRate || ''; // 费率sworkSheet.getCell('F23').value = tableData.robotDebugging_TotalCost || ''; // 价格sworkSheet.getCell('G23').value = tableData.robotDebugging_Remarks || ''; // 备注sworkSheet.mergeCells(`G23:L23`);// 项目经理费用sworkSheet.addRow();sworkSheet.getCell('A24').value = 10;sworkSheet.mergeCells(`B24:C24`);sworkSheet.getCell('B24').value = '项目经理费用';sworkSheet.getCell('D24').value = tableData.projectManagerFee_Hours || ''; // 小时数sworkSheet.getCell('E24').value = tableData.projectManagerFee_PerHourRate || ''; // 费率sworkSheet.getCell('F24').value = tableData.projectManagerFee_TotalCost || ''; // 价格sworkSheet.getCell('G24').value = tableData.projectManagerFee_Remarks || ''; // 备注sworkSheet.mergeCells(`G24:L24`);// 机械安装调试费用sworkSheet.addRow();sworkSheet.getCell('A25').value = 11;sworkSheet.mergeCells(`B25:C25`);sworkSheet.getCell('B25').value = '机械安装调试费用';sworkSheet.getCell('D25').value = tableData.mechanicalInstallationDebugging_Hours || ''; // 小时数sworkSheet.getCell('E25').value = tableData.mechanicalInstallationDebugging_PerHourRate || ''; // 费率sworkSheet.getCell('F25').value = tableData.mechanicalInstallationDebugging_TotalCost || ''; // 价格sworkSheet.getCell('G25').value = tableData.mechanicalInstallationDebugging_Remarks || ''; // 备注sworkSheet.mergeCells(`G25:L25`);// 电气安装调试费用sworkSheet.addRow();sworkSheet.getCell('A26').value = 12;sworkSheet.mergeCells(`B26:C26`);sworkSheet.getCell('B26').value = '电气安装调试费用';sworkSheet.getCell('D26').value = tableData.electricalInstallationDebugging_Hours || ''; // 小时数sworkSheet.getCell('E26').value = tableData.electricalInstallationDebugging_PerHourRate || ''; // 费率sworkSheet.getCell('F26').value = tableData.electricalInstallationDebugging_TotalCost || ''; // 价格sworkSheet.getCell('G26').value = tableData.electricalInstallationDebugging_Remarks || ''; // 备注sworkSheet.mergeCells(`G26:L26`);// 现场调试服务费sworkSheet.addRow();sworkSheet.getCell('A27').value = 13;sworkSheet.mergeCells(`B27:C27`);sworkSheet.getCell('B27').value = '现场调试服务费';sworkSheet.getCell('D27').value = tableData.onSiteDebuggingService_Hours || ''; // 小时数sworkSheet.getCell('E27').value = tableData.onSiteDebuggingService_PerHourRate || ''; // 费率sworkSheet.getCell('F27').value = tableData.onSiteDebuggingService_TotalCost || ''; // 价格sworkSheet.getCell('G27').value = tableData.onSiteDebuggingService_Remarks || ''; // 备注sworkSheet.mergeCells(`G27:L27`);// 售后服务费sworkSheet.addRow();sworkSheet.getCell('A28').value = 14;sworkSheet.mergeCells(`B28:C28`);sworkSheet.getCell('B28').value = '售后服务费';sworkSheet.getCell('D28').value = tableData.afterSalesService_Hours || ''; // 小时数sworkSheet.getCell('E28').value = tableData.afterSalesService_PerHourRate || ''; // 费率sworkSheet.getCell('F28').value = tableData.afterSalesService_TotalCost || ''; // 价格sworkSheet.getCell('G28').value = tableData.afterSalesService_Remarks || ''; // 备注sworkSheet.mergeCells(`G28:L28`);// 包装及运输费用sworkSheet.addRow();sworkSheet.getCell('A29').value = 15;sworkSheet.mergeCells(`B29:C29`);sworkSheet.getCell('B29').value = '包装及运输费用';sworkSheet.getCell('D29').value = '/'; // 小时数sworkSheet.getCell('E29').value = '/'; // 费率sworkSheet.getCell('F29').value = tableData.shippingPackagingCost_AfterMarkup || ''; // 价格sworkSheet.getCell('G29').value = tableData.shippingPackagingCost_Remarks || ''; // 备注sworkSheet.mergeCells(`G29:L29`);// 差旅费sworkSheet.addRow();sworkSheet.getCell('A30').value = 16;sworkSheet.mergeCells(`B30:C30`);sworkSheet.getCell('B30').value = '差旅费';sworkSheet.getCell('D30').value = '/'; // 小时数sworkSheet.getCell('E30').value = '/'; // 费率sworkSheet.getCell('F30').value = tableData.travelAndAccommodationCost_AfterMarkup || ''; // 价格sworkSheet.getCell('G30').value = tableData.travelAndAccommodationCost_Remarks || ''; // 备注sworkSheet.mergeCells(`G30:L30`);// 资料费sworkSheet.addRow();sworkSheet.getCell('A31').value = 17;sworkSheet.mergeCells(`B31:C31`);sworkSheet.getCell('B31').value = '资料费';sworkSheet.getCell('D31').value = '/'; // 小时数sworkSheet.getCell('E31').value = '/'; // 费率sworkSheet.getCell('F31').value = tableData.documentCost_AfterMarkup || ''; // 价格sworkSheet.getCell('G31').value = tableData.documentCost_Remarks || ''; // 备注sworkSheet.mergeCells(`G31:L31`);// 成本合计（小结）sworkSheet.addRow();sworkSheet.getCell('A32').value = 18;sworkSheet.mergeCells(`B32:C32`);sworkSheet.getCell('B32').value = '成本合计（小结）';sworkSheet.getCell('D32').value = '/'; // 小时数sworkSheet.getCell('E32').value = '/'; // 费率sworkSheet.getCell('F32').value = tableData.totalCost || ''; // 价格sworkSheet.getCell('G32').value = ''; // 备注sworkSheet.mergeCells(`G32:L32`);// 管理费sworkSheet.addRow();sworkSheet.getCell('A33').value = 19;sworkSheet.mergeCells(`B33:C33`);sworkSheet.getCell('B33').value = '管理费';sworkSheet.getCell('D33').value = '/'; // 小时数sworkSheet.getCell('E33').value = '/'; // 费率sworkSheet.getCell('F33').value = tableData.managementFee || ''; // 价格sworkSheet.getCell('G33').value = ''; // 备注sworkSheet.mergeCells(`G33:L33`);// 财务费sworkSheet.addRow();sworkSheet.getCell('A34').value = 20;sworkSheet.mergeCells(`B34:C34`);sworkSheet.getCell('B34').value = '财务费';sworkSheet.getCell('D34').value = '/'; // 小时数sworkSheet.getCell('E34').value = '/'; // 费率sworkSheet.getCell('F34').value = tableData.financialFee || ''; // 价格sworkSheet.getCell('G34').value = ''; // 备注sworkSheet.mergeCells(`G34:L34`);// 利润sworkSheet.addRow();sworkSheet.getCell('A35').value = 21;sworkSheet.mergeCells(`B35:C35`);sworkSheet.getCell('B35').value = '利润';sworkSheet.getCell('D35').value = '/'; // 小时数sworkSheet.getCell('E35').value = '/'; // 费率sworkSheet.getCell('F35').value = tableData.profit || ''; // 价格sworkSheet.getCell('G35').value = ''; // 备注sworkSheet.mergeCells(`G35:L35`);// 价格合计（未税）sworkSheet.addRow();sworkSheet.getCell('A36').value = 22;sworkSheet.mergeCells(`B36:C36`);sworkSheet.getCell('B36').value = '价格合计（未税）';sworkSheet.getCell('D36').value = '/'; // 小时数sworkSheet.getCell('E36').value = '/'; // 费率sworkSheet.getCell('F36').value = tableData.totalPriceExcludingTax || ''; // 价格sworkSheet.getCell('G36').value = ''; // 备注sworkSheet.mergeCells(`G36:L36`);// 增值税sworkSheet.addRow();sworkSheet.getCell('A37').value = 23;sworkSheet.mergeCells(`B37:C37`);sworkSheet.getCell('B37').value = '增值税';sworkSheet.getCell('D37').value = '/'; // 小时数sworkSheet.getCell('E37').value = '/'; // 费率sworkSheet.getCell('F37').value = tableData.valueAddedTax || ''; // 价格sworkSheet.getCell('G37').value = ''; // 备注sworkSheet.mergeCells(`G37:L37`);// 价格合计（含税）sworkSheet.addRow();sworkSheet.getCell('A38').value = 24;sworkSheet.mergeCells(`B38:C38`);sworkSheet.getCell('B38').value = '价格合计（含税）';sworkSheet.getCell('D38').value = '/'; // 小时数sworkSheet.getCell('E38').value = '/'; // 费率sworkSheet.getCell('F38').value = tableData.valueAddedTax || ''; // 价格sworkSheet.getCell('G38').value = ''; // 备注sworkSheet.mergeCells(`G38:L38`);// 数据行统一样式处理sworkSheet.eachRow((row, rowIndex) => {// 循环每一行if (rowIndex >= 14 && rowIndex <= 38) {if (rowIndex === 14) {// 标题行row.eachCell((cell, colIndex) => {console.log('cell', cell);cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};cell.font = { size: 11, bold: true };if (cell._address === 'D14' || cell._address === 'E14') {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: '00B0F0' } // 设置背景色};}});} else if (rowIndex >= 20 && rowIndex <= 28) {// 从机械设计 到 售后服务行row.eachCell((cell, colIndex) => {console.log('cell', cell);cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};if (cell._address.indexOf('B') > -1 || cell._address.indexOf('F') > -1) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'D9E1F2' } // 设置背景色};}if (cell._address.indexOf('D') > -1 || cell._address.indexOf('E') > -1) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: '00B0F0' } // 设置背景色};}});} else if (rowIndex === 32) {row.eachCell((cell, colIndex) => {console.log('cell', cell);cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};if (cell._address.indexOf('B') > -1 || cell._address.indexOf('F') > -1) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'E2EFDA' } // 设置背景色};}});} else if (rowIndex === 36) {row.eachCell((cell, colIndex) => {console.log('cell', cell);cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};if (cell._address.indexOf('B') > -1 || cell._address.indexOf('F') > -1) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'C6E0B4' } // 设置背景色};}});} else if (rowIndex === 38) {row.eachCell((cell, colIndex) => {console.log('cell', cell);cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};if (cell._address.indexOf('B') > -1 || cell._address.indexOf('F') > -1) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'A9D08E' } // 设置背景色};}});} else {row.eachCell((cell, colIndex) => {console.log('cell', cell);cell.font = { size: 11 };cell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};if (cell._address.indexOf('B') > -1 || cell._address.indexOf('F') > -1) {cell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'D9E1F2' } // 设置背景色};}});}row.height = 17;}});// 最下方针对报价其他说明列sworkSheet.addRow();sworkSheet.mergeCells(`A39:C39`);sworkSheet.mergeCells(`D39:L39`);let remarkcell = sworkSheet.getCell('A39');remarkcell.value = '针对此次报价的其他说明：';remarkcell.font = { size: 12, bold: true };remarkcell.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};remarkcell.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'A9D08E' } // 设置背景色};let remarkcell1 = sworkSheet.getCell('D39');remarkcell1.font = { size: 12 };remarkcell1.alignment = {vertical: 'middle', // 垂直居中horizontal: 'center', // 水平居中wrapText: true // 自动换行};remarkcell1.fill = {type: 'pattern',pattern: 'solid',fgColor: { argb: 'A9D08E' } // 设置背景色};sworkSheet.getRow(39).height = 20;// 将logo放入第一行 放到最后就行啦（复用总报价）// 前面已经加载了 imageid，这里直接用// 当前工作表（当前excel页）加入图片，tl.col：excel第几列，tl.row：excel第几行，ext里面表示图片宽高sworkSheet.addImage(imageId, {tl: { col: 0.1, row: 0.1 },// br: { col: columns.length + ai - 11.1, row: ri + 2 }ext: { width: 100, height: 85 }});// 调整所有列的宽度sworkSheet.columns.forEach((column) => {column.width = 17; // 将宽度设为20个字符});// 定义边框样式const borderStyle = {top: { style: 'thin' },left: { style: 'thin' },bottom: { style: 'thin' },right: { style: 'thin' }};// 遍历工作表中的所有单元格并添加边框sworkSheet.eachRow((row, rowIndex) => {row.eachCell((cell, colIndex) => {cell.border = borderStyle;});});}}await getData();// 保存工作簿workbook.xlsx.writeBuffer().then((buffer) => {saveAs(new Blob([buffer], { type: 'application/octet-stream' }), '商务报价单导出.xlsx');});} else {this.$message(res.msg);}loading.close();},
